50 Or 10ton Hanger Bridge Crane





50 Or 10ton Hanger Bridge Crane are composed of two main beams and one crossbeam to form a stable bridge structure. The main beam is connected to the ground through legs, and the lifting mechanism and driving mechanism are installed on the crossbeam. This design provides good load-bearing capacity and stability.

50 Or 10ton Hanger Bridge Crane can lift and carry heavy objects efficiently and is suitable for various heavy-duty operations. The crane can move on the track to cover a larger working range, which is convenient for operation in large workshops or warehouses. It usually ranges from a few tons to hundreds of tons to meet different operation needs. Depending on the specific model, the lifting height can reach a few meters to more than ten meters to adapt to different working environments. Different spans can be designed according to the layout of the workshop, with high flexibility.

3. 50 Or 10ton Hanger Bridge Crane are equipped with multiple safety devices, such as overload protection, emergency stop button and limit switch to ensure safe operation. At the same time, the structural design of the crane meets international standards and has good stability. The equipment is designed for easy maintenance, and regular inspection and maintenance can ensure its long-term and efficient operation. Manufacturers usually provide detailed operating manuals and maintenance guides to help users keep the equipment in the best condition. In summary, the double-girder bridge crane has become an indispensable and important equipment in heavy-duty handling operations with its superior performance, flexible application and strong carrying capacity, meeting the needs of modern industrial development.



Warranty:1 Year

Weight (KG):2000 kg

Feature:Bridge Crane

Condition:New

Rated Lifting Moment:5-500 tons

Max. Lifting Load:500 tons

Span:4.5-31.5m

Power supply:3 Phase AC 380V 50HZ

Control method:remote Control, pendent control,cabin control

Lifting mechanism:Electric Hoist or trolley

Crane type:Double Girder





50 Or 10ton Hanger Bridge Crane

1.Main beam

1. The main beam is usually composed of two parallel steel beams connected by a crossbeam in the middle to form a solid frame structure. The design of the main beam takes into account the distribution of force, the strength and stiffness of the material to ensure that the load can be effectively carried when lifting heavy objects.

2. The main beam generally uses high-strength steel (such as Q235 or Q345) with excellent tensile and bending resistance. The choice of material directly affects the load-bearing capacity and service life of the main beam.

3. The size and specifications of the main beam are determined according to the design parameters and application requirements of the crane, and usually consider factors such as lifting capacity, span and lifting height. Detailed mechanical analysis is required during design to ensure the safety and stability of the main beam.

4. The main beam needs to be accurately installed during the assembly process of the crane to ensure the coordination of various components. After installation, static and dynamic tests are required to verify its load-bearing capacity and stability. As the core component of the crane, the main beam needs to be inspected and maintained regularly, including weld inspection, surface anti-corrosion treatment and structural integrity assessment to ensure its long-term stable operation. The design and manufacture of the main beam must comply with national and industry standards and be equipped with necessary safety devices (such as limit switches, overload protection devices, etc.) to ensure safety during operation.

Lifting System

1. Hoisting mechanism

The hoisting system mainly consists of a motor, a reducer, a drum, a hook (or other slings) and a wire rope. The motor provides power, reduces the speed and increases the torque through the reducer, and the drum is responsible for retracting and releasing the wire rope.

2. Motor

The hoisting system usually uses a three-phase asynchronous motor with high power and stability. The selection of the motor depends on the lifting capacity and operating speed requirements of the crane.

3. Reducer

The reducer is used to reduce the speed of the motor and increase the output torque. Common types include gear reducers and worm reducers. Choose the appropriate model according to actual needs.

4. Drum

The drum is a component used to retract and release the wire rope. It is usually made of high-strength steel to ensure stable operation under high loads. The diameter and design of the drum will affect the operation and durability of the wire rope.



3.End carriage

1. Structural design

The end beam is usually a horizontal beam structure, which is connected to the main beam vertically to form a stable frame. Each end beam is equipped with a wheel group to support the movement of the crane on the track. The design of the end beam should take into account strength and rigidity to ensure stability when loaded.

2. Material selection

The end beam generally uses high-strength steel (such as Q235 or Q345) to ensure its load-bearing capacity and bending resistance. The choice of material directly affects the service life and safety of the end beam.

3. Main functions

Supporting function: The end beam is connected to the ground through the legs to provide overall support for the crane.

Wheel group installation: The wheel group is installed on the end beam to allow the crane to move smoothly on the track and ensure operational flexibility.

Connecting the main beam: The end beam is connected to the main beam to form a complete crane frame and transfer the load of the main beam.





4.Crane travelling mechanism

1. Components

The crane mechanism is usually composed of the following main components:

Motor: Provides power to drive the movement of the crane.

Reducer: Converts the high speed of the motor into a suitable low-speed high-torque output to drive the wheels.

Wheels: Contact the track, carry the weight of the crane and allow it to move smoothly.

Underframe: Supports the entire crane mechanism and is connected to the main beam.

2. Working principle

The crane mechanism drives the reducer through the motor, and the reducer transmits power to the wheels, pushing the crane forward and backward on the track. The control system can adjust the start, stop and running speed of the motor to achieve precise control.

5.Trolley travelling mechanism

1. Working principle

The trolley running mechanism drives the reducer through the motor, and the reducer transmits power to the wheels to push the trolley forward and backward on the main beam. The control system can adjust the start and stop and running speed of the motor to achieve precise control of the hoist.

2. Control method

The control methods of the trolley running mechanism usually include:

Manual control: manual operation through the control panel or handle.

Remote control: using a wireless remote control to increase operational flexibility and safety.

Automatic control: automatic control is achieved through PLC (programmable logic controller), which is suitable for integrated operation of the production line.

3. Safety device

The trolley running mechanism is usually equipped with a variety of safety devices to ensure safe operation:

Overload protection: when the load exceeds the rated value, it automatically stops running to protect the equipment.

Limit switch: prevents the trolley from exceeding both ends of the main beam to avoid equipment damage.

Emergency stop device: in an emergency, the operator can quickly stop the movement of the trolley.

6.Crane wheel

1. Material selection

The wheels are generally made of high-strength alloy steel or cast iron to ensure their strength and wear resistance under high load conditions. The choice of materials directly affects the service life and load-bearing capacity of the wheels.

2. Working principle

The wheels carry the weight of the crane and provide stable support by contacting the track. Driven by the motor, the wheels rotate and push the entire crane along the track. Good contact and friction ensure the safe and stable operation of the crane.

3. Design requirements

The design of the wheels needs to consider multiple factors:

Carrying capacity: According to the maximum load of the crane, the wheels need to have sufficient carrying capacity.

Friction coefficient: Ensure that there is appropriate friction between the wheels and the track to prevent slipping.

Wear resistance: The surface of the wheel needs to have good wear resistance to cope with long-term operation.

7.Crane Hook

1. Structural composition

The hook is usually composed of the following main parts:

Hook body: the main load-bearing part, usually made of high-strength steel, and the shape is designed to ensure the stability of the heavy object.

Hanging ring: used to connect the lifting wire rope or sling, which is convenient for connecting with the heavy object.

Safety lock: prevents the hanging object from accidentally falling off during the lifting process and increases safety.

2. Material selection

The hook generally uses alloy steel or special alloy materials to provide sufficient strength and toughness. The choice of materials directly affects the load-bearing capacity and durability of the hook.

3. Working principle

During the lifting operation, the hook is connected to the lifting wire rope through the hanging ring, and the hook body safely hangs the heavy object. When the lifting system is working, the hook lifts the heavy object through the wire rope to complete the handling task.

Motor

1. Types

Common motor types include:

AC motors: widely used in cranes, with advantages such as smooth start-up and high operating efficiency.

DC motors: suitable for occasions requiring speed regulation, with good control performance.

2. Maintenance and care

Regular maintenance is essential to the performance of the motor, including:

Lubrication: Regularly check and replace lubricating oil to ensure smooth operation of moving parts.

Electrical inspection: Check electrical connections and insulation to ensure safety.

Operation status monitoring: Monitor the working status of the motor to detect and solve problems in a timely manner.

.

Sound and light alarm system & limit switch

1. Sound and light alarm system

Warning function: When the crane is lifting, moving or operating, when it approaches a dangerous area or there is an abnormal situation, the system will send out sound and flash signals through the sound and light alarm device to remind the operator and surrounding personnel to pay attention to safety.

Status prompt: When the crane starts, stops, is overloaded or other important status changes, the sound and light alarm system will issue corresponding prompts to help the operator understand the equipment status in time.

2. Limit switch

Safety protection: The limit switch is used to limit the range of motion of the crane to prevent it from exceeding the safe working range and avoid equipment damage and accidents.

Automatic stop: When the crane reaches the preset limit, the limit switch will automatically cut off the power supply and stop the motor from working.

10.Safety Devices

1. Emergency stop device: In an emergency, the operator can quickly stop all movements of the crane to avoid accidents.

2. Sound and light alarm system: When the crane is working, if there is an abnormal situation (such as approaching the limit or overloading), the sound and light alarm system will emit sound and flash signals to remind the operator and surrounding personnel to pay attention.

3. Safety lock: used to prevent the hook or sling from accidentally falling off during the lifting process, increasing the safety of the lifting operation.

4. Electrical protection device: prevent the electrical system from overloading, short circuit or leakage, and ensure the safety of equipment and operators.

5. Safety cover: Cover vulnerable parts such as motors, transmission mechanisms, etc. to prevent operators from accidentally contacting them during work. The protective cover should have good visibility and durability, and be easy to operate and maintain.

6. Operation monitoring system: monitor the operating status of the crane in real time, record data, and issue an alarm when an abnormality occurs. Including sensors, display screens and control systems.

The safety device of double-beam bridge crane is an important guarantee to ensure the safe operation of the equipment. Reasonable design, regular maintenance and timely inspection can effectively reduce the risk of accidents and improve the safety and reliability of the crane. Operators should strictly follow the safety operating procedures to ensure that the hoisting operation is carried out in a safe environment.

11.Control Mode

1. Manual control: The operator directly controls the various actions of the crane, such as lifting and moving, through the control panel or handle. Simple and intuitive, suitable for small or short-time operations.

2. Remote control: Use a wireless remote control to control the operation of the crane, and the operator can control it from a safe distance. High flexibility, suitable for operations in complex or dangerous environments.

3. Automatic control: Automatic control is achieved through PLC (Programmable Logic Controller), which can automatically perform lifting operations according to preset programs. Improve efficiency and is suitable for high-frequency and repetitive operations.

4. Centralized control: Multiple cranes are centrally managed by a control center, and operators can monitor and control multiple devices at the same time. Suitable for large industrial sites to improve overall operation coordination.

5. Intelligent control: Combine sensors and monitoring systems to achieve intelligent monitoring and adjustment, such as real-time load monitoring and status feedback. Improve safety and efficiency and adapt to modern production needs.

6. Safety control: Equipped with safety protection devices (such as overload protection, limit switches) to ensure automatic shutdown under abnormal conditions. Enhance equipment safety and prevent accidents.

12.Sketch

Main technical



50 Or 10ton Hanger Bridge Crane

1. High load-bearing capacity

The double-beam design provides stronger structural rigidity, capable of carrying larger weights, and is suitable for heavy lifting operations.

2. Strong stability

Due to the double-beam structure, the crane is more stable during operation, reducing the risk of tilting and swaying, ensuring safety.

3. Large working range

Double-beam bridge cranes are usually equipped with long spans and heights, which can cover a larger working area and improve operating efficiency.

4. Flexible operation

Multiple control modes (manual, remote control, automatic, etc.) can be configured to adapt to different working environments and operating requirements.

5. Easy maintenance

The structural design makes the components easier to access and maintain, reducing maintenance costs and time.

6. Smooth operation

Due to the design of the double-beam structure, the crane runs more smoothly when lifting and moving, reducing the impact on the load.

7. High safety

Equipped with a variety of safety devices (such as limit switches, overload protection, etc.), it enhances the safety of operation and reduces the risk of accidents.

8. Wide range of applications

Widely used in manufacturing, warehousing, construction, logistics and other industries to meet diverse lifting needs.

9. High energy efficiency

Modern double-girder bridge cranes are usually designed to be energy-efficient, which reduces power consumption and improves economy.



50 Or 10ton Hanger Bridge Crane

1. Manufacturing Industry

In production lines and assembly workshops, double-girder bridge cranes are used to move and assemble heavy machines and components to improve production efficiency.

2. Construction sites

Used to hoist concrete prefabricated parts, steel structures and other building materials, helping construction units to carry out installation operations quickly and efficiently.

3. Warehousing and Logistics

In warehouses and distribution centers, double-girder bridge cranes are used for the handling, stacking and loading and unloading of heavy objects to improve the efficiency of material handling.

4. Mining Industry

In mines and mineral processing plants, double-girder bridge cranes are used to move heavy equipment and ores to adapt to harsh working environments.

5. Shipbuilding and Maintenance

Used for the construction, repair and dismantling of ships, it is convenient for the handling and positioning of large cargo.

6. Metallurgical Industry

In steel production and metal processing plants, double-girder bridge cranes are used to move heavy metal materials and equipment.

7. Energy Field

In power plants and wind farms, double-girder bridge cranes are used to install and maintain large equipment such as generators and fans.

8. Aerospace

Used to handle and assemble large components such as aircraft fuselages and engines during aerospace manufacturing.



50 Or 10ton Hanger Bridge Crane

1. Demand analysis: Communicate with customers to determine the specific parameters and usage requirements of the crane, such as lifting capacity, span, lifting height, etc. Carry out preliminary design and plan formulation according to customer needs.

2. Design stage: Use CAD and other design software for detailed structural design, including main beam, end beam, lifting mechanism, etc. Design control system, motor selection, power distribution system, etc. to ensure the safety and efficiency of the electrical system. Ensure that the design meets relevant safety standards and is equipped with necessary safety devices.

3. Material procurement: Select materials such as high-strength steel to ensure that the load-bearing and durability requirements are met. Purchase motors, reducers, crane rails, hooks and other accessories according to design requirements.

4. Processing and manufacturing: Cut, weld, drill and other processing of raw materials to manufacture various components, such as main beams, end beams, hooks, etc. Assemble the processed parts to form a complete crane structure.

5. Electrical installation: Carry out cable wiring and connection according to the electrical design drawings. Install control panels, remote controls, sensors and other equipment in place to ensure the normal operation of the electrical system.

6. Debugging and testing: Test the various functions of the crane, including lifting, moving, braking, etc., to ensure that it operates normally. Carry out load tests and safety performance tests to ensure the safety and stability of the crane under rated load.

7. Acceptance: Invite customers to conduct on-site acceptance to confirm whether the performance and design of the crane meet the requirements. Provide relevant technical documents, operating instructions and certificates of conformity.

8. After-sales service: Provide customers with installation guidance and technical support to ensure the smooth installation of the crane on site. Train operators to ensure that they have mastered the safe operation and maintenance knowledge of the crane. Provide regular maintenance and inspection services to ensure the long-term stable operation of the crane.















Material Inspection

Quality Inspection: Strict quality inspection is carried out on the purchased raw materials to ensure that they meet the design requirements and national standards.

Material Storage: Qualified materials are stored according to classification to prevent corrosion or damage.

Cutting and Forming

Steel Cutting: Use plasma cutting, laser cutting or flame cutting and other technologies to cut the steel according to the size of the design drawing.

Forming Processing: Form the steel plate through bending, rolling, welding and other processes to manufacture the main beam, end beam and other structural parts.

Welding

Component Welding: The cut and formed steel parts are welded into the main structures such as the main beam, end beam and trolley. The welding process needs to be strictly controlled to ensure the structural strength and welding quality.

Weld Inspection: Use non-destructive testing technology (such as ultrasonic testing, radiographic testing) to inspect the welds to ensure that there are no cracks or other defects.

Machining

Precision Machining: Precision machining is performed on the key components of the crane, such as wheel sets, bearing seats, pulleys, etc., to ensure their dimensional accuracy and surface quality.

Assembly of the whole machine

General assembly: On the basis of pre-assembly, the overall assembly of the crane is carried out, including the final installation of the main beam, end beam, lifting mechanism, walking mechanism, etc.

Commissioning and testing

Under dynamic conditions, the operating performance of the crane is tested, including the testing of lifting, walking, steering and other functions. The overall size of the assembled bridge crane is checked to ensure that all dimensions meet the design requirements.

Spraying and anti-corrosion treatment

Surface treatment Rust removal: Rust removal on the surface of the crane, common methods include sandblasting, pickling, etc. Primer spraying: Spray anti-corrosion primer on the treated surface to prevent metal oxidation and corrosion. Topcoat spraying Color spraying: Spray topcoat according to customer requirements or industry standards to give the crane a protective and decorative effect. Marking: After spraying, mark the crane's identification information in accordance with the specifications, such as model, rated load, etc.

Factory and installation

Packaging and transportation

Packaging protection: Protectively package the key components of the crane to prevent damage during transportation. Transportation arrangement: According to the equipment size and transportation conditions, select a suitable transportation method to transport the crane to the customer's site.

Acceptance and delivery

Customer acceptance

On-site acceptance: The customer conducts on-site acceptance of the crane according to the contract requirements and technical specifications to check the performance and quality of the equipment.

Problem rectification: If any problems are found, the manufacturer needs to rectify them in time to ensure that the equipment fully meets the customer's requirements. Delivery and use Operation training: The manufacturer usually trains the customer's operators to ensure that they can operate the crane correctly and safely.
