2000 Kgs Stationary Gantry Cranes



A 2000 kg stationary gantry crane is a fixed-position lifting system designed for handling and moving heavy loads up to 2,000 kilograms (2 metric tons). Unlike mobile gantry cranes, the stationary variant is securely anchored to a specific location, offering enhanced stability and precision for repetitive lifting operations in confined or designated work areas.

These cranes typically consist of a sturdy horizontal beam (girder) supported by two vertical legs, which are bolted or fixed to the floor or foundation. The crane's hoist and trolley travel along the beam to lift and move loads across the span. This configuration is ideal for environments where consistent lifting is required over a fixed area, such as workshops, assembly lines, warehouses, and maintenance bays.

Key Features:

Lifting capacity: 2000 kg (2 tons)

Fixed installation for high stability and reliability

Manual or electric hoist and trolley options

Customizable span and height to suit operational needs

Ideal for indoor applications or covered workspaces with limited mobility requirements

Stationary gantry cranes are valued for their cost-effectiveness, ease of installation, and ability to improve workflow efficiency by reducing manual handling and lifting fatigue. With fewer moving parts compared to mobile or overhead crane systems, they also offer low maintenance and high durability.



Core Components：Engine, Bearing, Gearbox, Motor, Gear

Place of Origin：Henan, China

Warranty：2 years

Weight (KG)：50000 kg

Video outgoing-inspection：Provided

Machinery Test Report：Provided

Application：Outdoor

Keywords：Gantry Crane

Rated Loading Capacity：50Ton

Cross travelling speed：44.6m/min

Long travelling speed：47.1m/min

Control way：cabin

Power supply：Cable reel

Steel track：QU80

Power：3-phase AC 50HZ 380V





1. Main Girder (Beam)

The horizontal beam that spans between the two legs.

Carries the hoist and trolley along its length.

Designed to support a maximum load of 2000 kg.

Support Legs (Columns)

Two vertical steel columns that support the main girder.

Anchored securely to the floor or foundation to keep the crane stationary and stable.



2. Hoist

The lifting mechanism used to raise and lower the load.

Can be manual (chain hoist) or powered (electric wire rope or chain hoist).

Mounted on the trolley and sized to handle up to 2000 kg.

Trolley

A movable carriage that runs along the main girder, carrying the hoist.

Enables horizontal movement of the load along the span of the crane.

Can be manual push-type or motorized.





3. End Stops

Installed at the ends of the main girder to prevent the trolley from running off the beam.

Ensures safety and protects equipment.

4.Crane travelling mechanism

1) Working principle

The wheels are attached to axles or wheel blocks that help in distributing the load evenly across the crane.The drive motor activates the wheels through a system of gears and reducers, converting the motor's rotational force into torque.The wheels, mounted on the frame of the crane, roll along the rails on which the gantry structure is placed.The power to the wheels is transmitted via a combination of chains, belts, or direct coupling depending on the design of the crane.The crane traveling mechanism of a Double Main Girder Gantry Crane involves synchronized wheel and motor systems that enable the crane to move along its designated rails, with additional features ensuring safe, balanced, and efficient operation.

2) Functions of the crane operating mechanism

Horizontal movement: The primary function of the crane travelling mechanism is to move the entire crane structure along the rails or tracks that are placed on the ground or the sides of the installation area.

Support and Stability:The travelling mechanism ensures the crane is securely supported on the rails or tracks. It helps distribute the weight of the crane evenly and provides stability during movement.

Power Transmission:The crane travelling mechanism is powered by electric motors that drive wheels or gear systems. These motors convert electrical energy into mechanical energy, propelling the crane forward or backward.

Load Distribution:The travelling mechanism helps distribute the load evenly across the crane's wheels and tracks, preventing damage and ensuring the durability of the crane and its components.

5.Trolley travelling mechanism

1) Structural composition

Trolley frame: The frame is typically made of high-strength steel to support the load and withstand the stresses during operation.

Wheel set: The trolley is equipped with wheels that run on the rails of the main girder. These wheels are often made of hardened steel or cast steel to ensure durability and wear resistance.

Drive device: Electric motors are commonly used to provide the necessary power for the trolley's movement A gearbox is used to control the speed and torque of the trolley's movement.Couplings connect the motor to the gearbox and ensure smooth transmission of power to the wheels.

.

2) Function of the trolley operating mechanism

Horizontal Movement: The primary function of the trolley traveling mechanism is to move the trolley horizontally across the length of the main girders. This movement allows the crane to position the hoist over a desired load location.

Load Handling: By moving along the main girders, the trolley helps in positioning the hoist system accurately above the load, which is necessary for lifting and transferring goods efficiently.

Power Transmission: The traveling mechanism typically uses electric motors and gear systems to provide the necessary torque and speed for the trolley's movement. The motors can be either AC or DC, depending on the design and requirements of the crane.

Rails and Wheels: The trolley runs on rails that are mounted on the main girders. The wheels on the trolley are designed to travel along these rails, ensuring smooth and stable movement. The wheels may be fitted with flanges to prevent lateral movement and maintain alignment.

Safety Mechanisms: The traveling mechanism is equipped with safety features such as limit switches, braking systems, and overload sensors to prevent accidents and ensure the safe operation of the crane.

6.Crane wheel

1) Function of wheels

Load Bearing: In a double main girder gantry crane, each wheel supports a significant portion of the crane's load. The wheels must be engineered to handle both the static and dynamic loads imposed during lifting operations.

Material Handling and Safety: The design of crane wheels must ensure safe operation, especially when handling heavy or oversized loads. The wheels should be engineered to minimize noise and vibrations during operation.

Rail Compatibility: Crane wheels are designed to run on specific rail types (e.g., flat or curved tracks). The size and shape of the wheel flange must match the rail profile to ensure proper fit and smooth operation.

2) Design requirements

Material and Design: Crane wheels are typically made of high-strength steel or cast iron to withstand the heavy loads and stresses associated with lifting and transporting materials. The design often includes a flange to ensure proper alignment and prevent the wheels from derailing off the tracks.

7.Crane Hook

The crane hook of a double main girder gantry crane is an essential component used for lifting and transporting heavy loads.

Design and Structure

Material: Typically made of high-strength steel to withstand heavy loads and provide durability.

Shape: The hook often has a C-shape or a pointed end for securely holding lifting slings or chains.

Size and Capacity: It is designed to match the lifting capacity of the crane, which can range from a few tons to several hundred tons for large industrial cranes.

Types of Hooks

Single Hook: Common in standard applications, used for lifting a load from a single point.

Double Hook: Utilized when a more balanced load is needed, often in double main girder designs for higher lifting capacities.

Crab Hook: In gantry cranes, the hook may be mounted on a trolley or crab that runs along the girders.

Motor

The motor of a double main girder gantry crane is an essential component that provides the power necessary for lifting, traveling, and sometimes rotating the crane's hoist or trolley system.The motor's power rating must match the crane's capacity and the load it needs to lift. Typically, these motors range from a few kilowatts up to hundreds of kilowatts, depending on the lifting and traveling requirements.

Motors can be equipped with variable frequency drives (VFDs) for smooth speed adjustments and energy savings.Safety and control systems like overload protection, braking systems, and emergency stops are incorporated for safe operation.

The motor should be compatible with the electrical supply available at the operating site, which can vary (e.g., 380V/50Hz, 480V/60Hz).The motor in a double main girder gantry crane is used for operations such as lifting heavy loads, moving the crane along the tracks (longitudinal travel), and sometimes lateral movement (cross travel) of the hoist or trolley.

.

Sound and light alarm system & limit switch

1) Sound and light alarm system

A double main girder gantry crane, commonly used in heavy-duty operations, often incorporates safety mechanisms like sound and light alarm systems to ensure safe operations.

Sound Alarm (Horns/Buzzers): These are typically loud, audible devices that emit a distinctive sound to alert people in and around the working area. The sound level is designed to be high enough to be heard over operational noise.

Light Alarm (Flashing Lights/Beacons): Visual signals, such as flashing lights or rotating beacons, help alert personnel visually, especially in noisy environments where sound alarms may be insufficient.

2) Limit switch

A limit switch on a Double Main Girder Gantry Crane is a safety device used to prevent the crane from moving beyond a designated range. This ensures the protection of both the crane and its surroundings, as well as any loads being lifted.

Key Functions of Limit Switches:

Position Control: The limit switch helps monitor and control the position of the crane's trolley, hoist, and gantry to prevent over-travel and collisions.

Safety Shutdown: If the crane moves past its allowed limits, the limit switch signals the control system to stop the motor and prevent damage or hazardous situations.

Emergency Stop: It can act as an emergency cutoff to shut down the crane when it approaches the limits of its track or rail, preventing it from derailing or causing accidents.

Types of Limit Switches Used:

Mechanical Limit Switches: Activated by physical contact, often using a lever or cam that triggers the switch when moved by the crane's motion.

Electronic Limit Switches: Use sensors (e.g., inductive, capacitive, or optical sensors) for non-contact detection, providing higher durability and reducing wear and tear.

Rotary Limit Switches: Typically used in applications where rotational motion needs to be monitored, such as in hoists.

Linear Limit Switches: Used for applications where linear travel is monitored, commonly found in the movement of the trolley.

10.Safety Devices

1) 1. Overload Protection Device

Function: Prevents the crane from lifting loads that exceed its rated capacity.

2. Limit Switches

Function: Prevents the crane from moving beyond a set range during operations.

3. Emergency Stop Button

Function: Allows operators to quickly shut down the crane in case of an emergency.

4. Anti-Collision Device

Function: Prevents collisions between the crane and other structures or equipment.

5. Load Sway Control

Function: Reduces load sway during operations, which can be dangerous if uncontrolled.

6. Brake Systems

Function: Ensures that the crane remains in a stationary position when not in motion.

7. Safety Interlocks

Function: Prevents the operation of the crane if certain safety conditions are not met.

8. Warning Alarms and Signal Lights

Function: Alerts personnel in the vicinity of the crane's movement.

9. Anti-Tipping Device

Function: Protects against crane tipping due to uneven load distribution or excessive loading.

10. Cooling System for Motors

Function: Prevents motors from overheating during extended use.

11. Remote Control Systems

Function: Allows operators to control the crane from a safe distance.

12. Crane Monitoring Systems

Function: Provides real-time monitoring of operational parameters such as load weight, speed, and position.

13. Lighting and Visibility Aids

Function: Ensures that the operator has clear visibility, especially in low-light conditions.

11.Control Mode

1)1. Pendant Control

Description: The crane operator uses a wired control pendant to manage the movement of the crane and hoist.

Advantages: Simple to use, cost-effective, and provides direct control from a safe distance.

Usage: Commonly used in stationary or semi-stationary operations where the operator can be close to the crane.

2. Radio Remote Control

Description: Operators use a wireless control unit, which communicates with the crane via radio signals.

Advantages: Offers more flexibility as the operator can control the crane from a greater distance and access hard-to-reach areas.

Usage: Ideal for more complex operations and environments where operator mobility is essential.

3. Cabin Control

Description: The operator sits in a cabin on the crane itself and controls it using a combination of joysticks, buttons, or other controls.

Advantages: Provides a better view of the working area and greater precision in controlling the crane.

Usage: Suitable for heavy-duty operations or when a higher level of control is needed for positioning and maneuvering.

4. Automated Control (Semi-Automatic and Fully Automated)

Description: The crane can be controlled by programmed commands or integrated with automated systems for autonomous operation.

Advantages: Reduces human intervention, improves precision, and enhances safety for repetitive tasks.

Usage: Often used in large-scale operations where high efficiency and continuous operation are necessary.

5. Hybrid Control

Description: Combines manual operation (using pendant, remote, or cabin control) with automated features that can be engaged as needed.

Advantages: Offers versatility for operators who need to switch between manual and automated modes for specific tasks.

Usage: Common in systems designed to be adaptable to various operational requirements.

12.Sketch



Main technical







Here are the key advantages of a 2000 kg stationary gantry crane:

---

Advantages of a 2000 kg Stationary Gantry Crane

High Stability

Fixed installation provides a solid and stable structure, ideal for repetitive lifting operations in a specific work area.

Cost-Effective Solution

Generally more affordable than overhead or mobile cranes, especially for small to medium lifting capacities like 2000 kg.

Space Optimization

Ideal for workshops, production lines, and maintenance bays where lifting needs are confined to a set area.

Ease of Installation

Simple to assemble and install with minimal structural modification to the building or floor.

Reliable Performance

Minimal moving parts reduce wear and tear, resulting in lower maintenance requirements and longer service life.

Enhanced Safety

Anchored legs and stationary design reduce risks of tipping or accidental movement during operation.

Customization Options

Can be designed with custom spans and heights to meet specific lifting requirements and workspace layouts.

Manual or Powered Operation

Flexibility to choose between manual hoists for lighter-duty use or electric hoists and trolleys for more efficient operation.

Improved Ergonomics

Reduces manual lifting strain on workers, leading to a safer and more efficient working environment.

Minimal Floor Obstruction

Legs can be positioned at the workspace edges, keeping the central floor area mostly free and accessible.







Here's a list of common applications for a 2000 kg stationary gantry crane:

---

Applications of 2000 kg Stationary Gantry Crane

Workshops and Fabrication Shops

Ideal for lifting and positioning machine parts, tools, and metal components during assembly or repair processes.

Maintenance Bays

Used in vehicle or equipment maintenance areas to lift engines, transmissions, and other heavy parts safely and efficiently.

Warehouse and Storage Facilities

Assists in loading and unloading goods, moving inventory between storage areas, or placing heavy items on racks.

Manufacturing and Assembly Lines

Supports repetitive lifting tasks such as moving semi-finished products between production stages or workstations.

Mold and Die Handling

Common in industries like plastic or metal molding for lifting and changing heavy molds and dies.

Small Foundries and Machine Shops

Used for handling castings, metal stock, or heavy equipment during fabrication or inspection.

Test Labs and R&D Facilities

Facilitates the safe handling of prototypes, machinery, or instruments during testing procedures.

Construction Pre-Assembly Zones

Useful for pre-assembling components such as panels, frames, or small structures before installation.

Tool and Equipment Loading Areas

Can be placed near loading docks or tool storage areas for handling large equipment or crates.

Aerospace and Automotive Sectors

Supports precise and clean lifting operations in areas where delicate handling of parts and components is critical.







1. Design and Engineering

Blueprint and Structural Design: Engineering teams design the crane based on specifications, considering the weight, span, lifting capacity, and working environment.

Component Specifications: Detailed specifications for components such as the main girders, end beams, hoist system, trolley, and electrical components are prepared.

2. Material Selection and Procurement

Steel Material Selection: High-strength steel materials are chosen for the main girders, columns, and other critical parts.

Procurement: Materials, such as steel plates, sections, bolts, and electrical components, are sourced and inspected for quality.

3. Cutting and Pre-Fabrication

Cutting and Shaping: Steel components are cut, shaped, and welded into preliminary forms according to the design specifications.

Pre-Fabrication Assembly: Components such as beams and girders are pre-assembled to verify that they fit together properly.

4. Welding and Structural Assembly

Welding: Main girders, columns, and other structural components are welded to create a sturdy framework. Specialized welding techniques are used to ensure strength and durability.

Structural Assembly: The main girders and end beams are assembled, ensuring precise alignment for balanced load distribution.

Quality Control: Welding seams and joints are inspected using non-destructive testing (e.g., ultrasonic or X-ray testing) for any structural defects.

5. Machining and Finishing

Machining of Parts: Critical parts such as the wheels, trolley components, and hoists undergo machining for proper fitting and smooth operation.

Surface Treatment: Steel parts are cleaned and subjected to surface treatments like sandblasting and coating to prevent rust and enhance durability.

Painting and Coating: Protective coatings are applied for weather resistance, with a primer followed by top coats.

6. Assembly of Crane Components

Main Girder Assembly: The two main girders are mounted and aligned.

End Beam Installation: End beams are fixed to the main girders, forming the frame of the crane.

Hoist and Trolley Installation: The hoist mechanism and trolley are mounted on the main girder rails and tested for alignment and operational smoothness.

7. Electrical and Control Systems Installation

Wiring and Cabling: Electrical wiring is installed for power supply, control circuits, and safety systems.

Control Panel and Safety Features: The control panel is mounted, with safety features such as limit switches, emergency stops, and overload protection integrated and tested.

Control System Programming: The crane's control system is programmed and tested for correct operation.

8. Testing and Quality Assurance

Load Testing: The crane is subjected to load tests to ensure it can handle its rated capacity without issues.

Operational Testing: Functional tests are performed to check movements, responsiveness, braking systems, and electrical operations.

Inspection and Certification: The crane undergoes final inspections to verify compliance with safety regulations and standards. Certification may be issued by relevant authorities.

9. Final Adjustments and Delivery Preparation

Final Adjustments: Any minor adjustments are made to ensure smooth operation.

Documentation: Operation manuals, maintenance guidelines, and certification documents are prepared for delivery.

Packaging and Shipping: The crane is packaged securely for shipment, ensuring all parts are protected during transit.

10. Installation and Commissioning (at Site)

On-site Assembly: The crane is assembled at the customer's location if required.

Workshop view:

The company has installed an intelligent equipment management platform, and has installed 310 sets (sets) of handling and welding robots. After the completion of the plan, there will be more than 500 sets (sets), and the equipment networking rate will reach 95%. 32 welding lines have been put into use, 50 are planned to be installed, and the automation rate of the entire product line has reached 85%.
