600ton Bridge Girder Erecting Machine

A 600 ton Bridge Girder Erection Machine (GEM) is a heavy-duty piece of equipment used in the construction of large bridges, particularly for lifting and placing precast concrete or steel girders. Below are the key components of such a machine:





A 600 ton bridge girder erecting machine is a heavy-duty piece of equipment used in the construction of large bridges, particularly for lifting and placing precast concrete or steel girders into position. These machines are essential for building viaducts, highway overpasses, and railway bridges efficiently and safely.

Key Features of a 600-Ton Bridge Girder Erecting Machine:
High Load Capacity – Designed to lift and position girders weighing up to 600 metric tons.

Adaptability – Can handle different girder types (T-beams, box girders, U-beams) and spans.

Mobility – Often mounted on a self-propelled modular transporter (SPMT) or rail-based system for movement along the bridge deck.

Stability & Safety – Equipped with hydraulic balancing systems, outriggers, and anti-sway mechanisms.

Automation & Control – Advanced PLC-based controls for precision lifting and alignment.

Modular Design – Some models can be disassembled and transported to new construction sites.





600-Ton Beam Launcher Crane Specification
1. General Specifications
Capacity: 600 metric tons (max lifting capacity)

Type: Modular/self-launching gantry crane or rail-mounted launcher

Application: Precast beam erection (e.g., box girders, U-beams, T-beams for bridges)

Design Standards: ISO 4301, FEM 1.001, EN 13001, ASME B30.2









1. Main Structural Components
Main Girder/Beam – The primary load-bearing structure that spans the construction gap and supports the lifting mechanism.

Supporting Legs/Outriggers – Provide stability and distribute the load to the bridge piers or temporary supports.

Traveling Mechanism – Includes rails, wheels, or crawlers to move the machine along the bridge deck or temporary tracks.

2. Lifting System
Hoisting Winches – Electric or hydraulic winches with high-capacity cables for lifting girders.

Lifting Frames/Spreaders – Adjustable frames to securely hold girders during lifting.

Hydraulic Jacks – Used for fine adjustments in girder positioning.

Wire Ropes & Pulleys – High-strength steel cables for load handling.

3. Movement & Positioning System
Longitudinal Travel System – Allows the machine to move forward/backward along the bridge alignment.

Transverse Adjustment System – Enables side-to-side movement for precise girder placement.

Rotation Mechanism (if applicable) – Some machines can rotate girders for angled placements.

4. Power & Control System
Hydraulic Power Unit (HPU) – Provides hydraulic pressure for lifting and movement.

Electrical Control Panel – Houses PLCs, sensors, and automation controls.

Remote Control System – Allows operators to control movements wirelessly for safety.

5. Safety & Auxiliary Components
Anti-Sway System – Reduces oscillations during girder lifting.

Load Monitoring System – Ensures the load does not exceed capacity (600 tons).

Emergency Brakes & Locking Devices – Prevents accidental movements.

Anchoring System – Secures the machine to the bridge deck or piers during operations.

Work Platforms & Ladders – For maintenance and inspection access.

6. Temporary Supports & Auxiliary Equipment
Launching Nose (for cantilever erection) – Extends the machine's reach for girder placement.

Temporary Piers/Supports – Used when the machine spans between piers.

Alignment Tools – Lasers or GPS for precise girder positioning.









A 600 ton Bridge Girder Erection Machine (BGM) is a heavy-duty piece of equipment used in the construction of large bridges, particularly for placing precast concrete or steel girders. Here are its key advantages:

1. High Load Capacity
Can handle ultra-heavy girders (up to 600 tons), making it suitable for long-span bridges (e.g., highway, railway, and sea-crossing bridges).

Reduces the need for multiple cranes or temporary supports.

2. Precision and Stability
Equipped with computer-controlled hydraulic systems for accurate girder alignment.

Ensures safe and stable lifting, minimizing human error.

3. Efficiency & Speed
Speeds up construction by lifting and placing girders in a single operation.

Reduces assembly time compared to traditional methods (e.g., cranes or launching gantries).

4. Adaptability
Works in challenging terrains (mountains, rivers, urban areas).

Adjustable supports and booms allow for different girder lengths and bridge geometries.

5. Safety Enhancements
Automated safety systems (load monitoring, anti-sway, emergency brakes).

Reduces risks of accidents during heavy lifting operations.

6. Cost-Effectiveness
Lowers labor costs by reducing manual handling.

Minimizes the need for temporary supports or falsework, saving material costs.

7. Reduced Environmental Impact
Fewer machines on-site mean lower noise and emissions.

Less disruption to surrounding areas compared to multiple cranes.

8. Versatility in Bridge Types
Suitable for segmental, box girder, T-beam, and steel truss bridges.

Used in balanced cantilever, incremental launching, and span-by-span construction.

9. Long-Term Durability
Built with high-strength steel and wear-resistant components, ensuring longevity even in harsh conditions.

10. Compliance with Modern Standards
Meets international safety and performance standards for heavy lifting and bridge construction.





A 600 ton bridge girder erecting machine is a heavy-duty piece of equipment designed for the precise placement of large bridge girders, segments, or precast concrete beams during bridge construction. These machines are essential for building viaducts, highway overpasses, railway bridges, and other large-span structures.

Key Applications:
Highway & Expressway Bridges

Used to install precast concrete girders (I-beams, U-beams, T-beams, box girders) for elevated roads and interchanges.

Suitable for balanced cantilever construction in segmental bridges.

Railway Bridges

Erects heavy girders for high-speed rail and conventional railway bridges.

Handles long-span steel trusses or composite girders.

Urban Viaducts & Flyovers

Places girders in congested urban environments where traditional cranes may not be feasible.

Enables rapid construction with minimal traffic disruption.

River & Valley Crossings

Used in the construction of long-span bridges over rivers, gorges, or difficult terrains.

Can work in conjunction with launching gantries for incremental launching.

Segmental Bridge Construction

Lifts and positions precast segments for balanced cantilever or span-by-span erection.

Often used with a launching girder for continuous span bridges.

Heavy Girder Installation

Handles steel box girders, composite girders, or heavy concrete beams exceeding 500 tons.

Used in cable-stayed or suspension bridge deck construction.





The production procedure for a 600 ton bridge girder erecting machine involves several stages, including design, material procurement, fabrication, assembly, testing, and commissioning. Below is a detailed step-by-step procedure:

1. Design & Engineering
Requirement Analysis: Determine load capacity (600 tons), span length, lifting height, and operational conditions.

Structural Design: CAD modeling of the main girder, supports, lifting system, and hydraulic/pneumatic systems.

Mechanical & Electrical Systems: Design of winches, motors, control systems, and safety mechanisms.

Simulation & Validation: Finite Element Analysis (FEA) to ensure structural integrity under load.

2. Material Procurement
High-Strength Steel: For main girders, booms, and support structures.

Hydraulic Components: Pumps, cylinders, valves, and hoses.

Electrical & Control Systems: PLCs, sensors, motors, and cables.

Fasteners & Bearings: High-tensile bolts, pins, and heavy-duty bearings.

3. Fabrication of Components
A. Main Girder Fabrication
Cutting & Shaping: CNC plasma/oxy-fuel cutting of steel plates.

Welding: Submerged arc welding (SAW) for high-strength joints.

Machining: Drilling and milling for bolt holes and connections.

Surface Treatment: Sandblasting and painting for corrosion resistance.

B. Support Structure (Legs/Outriggers)
Fabrication of telescopic or fixed supports with locking mechanisms.

Integration of hydraulic cylinders for height adjustment.

C. Lifting System
Assembly of winches, wire ropes, and pulleys.

Installation of hydraulic jacks or synchronous lifting system.

D. Electrical & Control System
Mounting of PLC, HMI, sensors, and limit switches.

Wiring and integration with hydraulic systems.

4. Assembly
Base Frame Assembly: Mounting support legs and stabilizers.

Main Girder Installation: Lifting and securing the girder onto supports.

Mechanical Systems: Installing winches, trolleys, and lifting beams.

Hydraulic & Electrical Integration: Connecting pumps, valves, and control panels.

5. Testing & Quality Control
Load Testing:

Static load test (1.25 × 600 tons = 750 tons) to check deformation.

Dynamic load test (1.1 × 600 tons = 660 tons) to simulate real operation.

Functional Testing:

Movement of trolley, lifting, and lowering operations.

Emergency stop and safety system checks.

Non-Destructive Testing (NDT): Ultrasonic, magnetic particle, or X-ray inspection of critical welds.

6. Commissioning & Delivery
On-Site Assembly: Transporting components to the construction site and reassembling.

Final Testing: Operational checks under real conditions.

Operator Training: Safety and operational procedures for end-users.

7. Maintenance & Documentation
Manual Preparation: User manuals, maintenance schedules, and troubleshooting guides.

After-Sales Support: Technical assistance and spare parts supply.
