L Type Hoist Gantry Crane



L type single girder gantry crane with hook is applied for handling and convey operation outdoors, or at warehouse, stock ground, railway station, sea port cargo area, etc.

Product Name: L Type Single Girder Gantry Crane

Lifting Capacity: 5t-50/10t

Span: 18-22m, 30-35m

Lifting Height: 10, 11, 12m





1.Bridge: The bridge is the horizontal beam that supports the hoist mechanism and moves along the runway beams.

2.Legs: The legs are the vertical columns that support the bridge and are fixed to the ground or runway beams.

3.Hoist mechanism: The hoist mechanism is used to lift and move loads along the bridge. It consists of a drum, wire rope, hook block, and electric motor.

4.Runway beams: The runway beams are the tracks on which the crane moves back and forth.

5.Travel drive: The travel drive is used to move the crane along the runway beams. It consists of an electric motor, gearbox, and wheels.

6.Control system: The control system is used to operate the crane. It consists of a pendant station or wireless remote control.

7.Safety devices: Safety devices such as limit switches, overload protection, and emergency stop buttons are installed on the crane to ensure safe operation.

8.Sketch:





Manufacturing Plants: In manufacturing facilities, L Type Hoist Gantry Cranes are used for lifting and moving heavy materials or components during the production process. They are particularly useful in assembly lines where items need to be transported from one station to another.

Metal Recycling: In metal recycling operations, L Type Hoist Gantry Cranes are utilized to handle scrap metal, loading it onto trucks or transporting it within the facility.

Machine Maintenance: L Type Hoist Gantry Cranes are used in machine shops for maintenance tasks, such as lifting engines or heavy machinery components for repair or replacement.

Warehouses: In warehouses, these cranes facilitate the storage and retrieval of goods, especially large or heavy items that cannot easily be moved by forklifts or manual labor.

Shipyards: For shipbuilding and maintenance,L Type Hoist Gantry Cranes are used to move materials and equipment to and from the vessels under construction or repair.

Rail Yards: In rail yards, these cranes are employed for loading and unloading railroad cars with goods and materials.







The company has installed an intelligent equipment management platform, and has installed 310 sets (sets) of handling and welding robots. After the completion of the plan, there will be more than 500 sets (sets), and the equipment networking rate will reach 95%. 32 welding lines have been put into use, 50 are planned to be installed, and the automation rate of the entire product line has reached
